Hot Splicing Vulcanizing Press

Product Details

Features :
1. The control box is water-repellent design.
2. Electric parts is Siemens brand.
3. LCD digital automatic control system.
4. Material is high strength light alloy, one piece structure ,easy to carrying.

Main parameter:

NO. Version WH-1000×830
1 Apply the width of belt(mm) B=1000
2 Working pressure(Mpa) 1.0-1.5
3 Working temperature°C 145°C±5°C
4 Temperature rising time (min) ≤30
5 Power (KW) 15
6 Working voltage (V) AC=380
7 Electric cabinet output power(KW) 36
8 Adjust range of timing(min) 0~99
9 Overall size (L* W * H) 1692×830×585
10 Size of plate (mm) 830×1228
11 Quantity of plates 2 pcs
12 Max weight of big parts(kg) 82
13 Weight(kg) 600
14 Manual hydraulic pump S-SY12.5/4
15 Outlet pressure of hydraulic test pump (Mpa) 4
