Usage :
The machine applies to vulcanizing various kinds of model rubber and plastic products as well as non-model products.
Main parameter:
| Model | XLB-D400x400 | XLB-D500x500 | XLB-D600x600 |
| Total Pressure | 0.63MN | 0.63/1.0MN | 1.0MN |
| Max Hydraulic Pressure | 16Mpa | 16Mpa | 16Mpa |
| Heating Platen Size | 400x400mm | 500x500mm | 600x600mm |
| Space of Heating Platen | 125mm | 125mm | 125mm |
| Working layers | 2 | 2 | 2 |
| Plunger Stroke | 250mm | 250mm | 300mm |
| Total Heating Power | 9Kw | 10.8Kw | 18.9Kw |
| Pump Power | 1.5+1.1kw | 1.5+1.1kw | 3+3kw |
| Dimension | 1680x430x1500mm | 1780x530x1600mm | 2260x630x1800mm |
| Weight | 1500kgs | 2000kgs | 3500kgs |
